The Infoblox Application Layer

Use the tests associated with this layer to figure out the messages transmitted/received through various protocols, the number of queries for which the reply was from an authoritative server, the time taken to respond to such queries etc. This layer on the whole helps administrators to analyze the efficiency of an Infoblox appliance in the target environment.

layer 1 green

Figure 1 : The tests mapped to the UPS Service layer
