Monitoring Cisco Catalyst Switches

eG Enterprise has developed an exclusive Cisco Catalyst Switch monitoring model (see Figure 1), which periodically checks the traffic to and from the switch and the temperature of the switch, so that deviations can be detected before any irrepairable damage is done.

layermodel-final

Figure 1 : Layer model of the Cisco Catalyst Switch

Each of the layers of Figure 1 has been briefly discussed in the sections to come.
